Specification
| General Requirements | |||
| 1 | EV Charger Type | DC | |
| 2 | Charger Capacity | 160KW/180KW | 240KW |
| 3 | Product Model NO. | SP-DC-160/180-EVC | SP-DC-240-EVC |
| 4 | Mounting | Ground-Mounted | |
| lnput Requirements | |||
| 5 | AC Supply System | Three-Phase,5 Wire AC system | |
| 6 | Nominal lnput Voltage | AC380V±15% | |
| 7 | Input Frequency | 45-65Hz | |
| Environmental Requirements | |||
| 8 | Ambient Temperature Range | -25 to55℃ | |
| 9 | Ambient Humidity | 5 to 95% | |
| 10 | Storage Temperature | -40 to 70°℃ | |
| Mechanical Requirements | |||
| 11 | IP Ratings | IP54 | |
| 12 | Cooling | Air-cooled | |
| Output Requirements | |||
| 13 | Number of Outputs | 1or2 | 2 |
| 14 | Type of Each Output | DC200-750V DC150-500V(JIS) | |
| 15 | Single Output Max.Current | 200Amp | |
| 16 | Power Factor | 20.99(50%load above) | |
| User Interface &Display Requirements | |||
| 17 | Display &Touch-Screen Size | 7Inches Touch Screen with Shell | |
| 18 | User Authentication | Mobile Application or User Interface/QR Code/RFID Card/Password Login | |
| 19 | Metering Information | Consumption Units | |
| Communication Requirements | |||
| 20 | Communication between EVSE and Central Server | OCPP 1.6J Protocol (Optional) | |
| 21 | Interface between Charger and CMS | Ethernet/3G/4G/WIFI (Optional) | |
| Protection &Safety Requirements | |||
| 22 | Executive Standard | IEC62196 2017,IEC61851 2017,SAE J772,CHAdeMO etc. | |
| 23 | Safety Parameters | Over Current,Under Voltage,Residual Current,Surge Protection,Leakage Protection, Short Circuit,Over Temperature,etc. | |
Producing and Packing
Project Case
FAQ
What is the charging capacity of Sunpal DC EV Charger?
We are available in 160kW, 180kW, and 240kW models, providing fast and efficient charging solutions for electric vehicles.
